Centring rail
The new centring rail ensures maximum safety when picking up, positioning, and setting down containers. It is suitable for all common types of containers and offers exceptional flexibility in daily use.
All MULTIPRESS compactors are equipped with an integrated fire suppression system as standard, thereby making a significant contribution to preventive fire protection. In the event of a fire, the system enables both operators and firefighters to effectively prevent the fire from spreading to buildings and adjacent structures. By directly connecting a water hose, the compactor can be flooded without having to open or move it.
All PÖTTINGER compactors come powder-coated as standard and are available in all RAL colors. The solvent-free powder coating provides optimal corrosion protection, high durability, and a long service life. After cleaning and sandblasting (RA 2½), the components are primed and coated with a topcoat powder. A minimum coating thickness of 120 µm and curing at approximately 200 °C ensure a particularly robust, impact- and abrasion-resistant surface.
PÖTTINGER Multipress compactors come standard with a low-noise pump. The machine operates at less than 59 dBA when idling.
The rear door or tailgate of PÖTTINGER compactors comes standard with an 8-point locking system and ensures a high level of liquid tightness. The integrated transport hook allows for secure loading onto a truck. The safety release and door catch ensure maximum safety. If requirements change, the rear wall can be easily converted from a door to a flap thanks to its modular design, without the need for extensive modifications.
All PÖTTINGER compactors come standard with a phase inverter and a connection for a remote control, enabling flexible and safe commissioning. The optional convenience package enhances ease of use and efficiency in daily operation: an automatic full-bin notification system via text message for on-demand and cost-effective pickup, an electric lid opener for convenient handling, and a button for the tipping mechanism for simple and safe operation.
| MULTIPRESS 1.9 | MP 16-1.9 | MP 18-1.9 | MP 20-1.9 | MP 22-1.9 | MP 24-1.9 |
|---|---|---|---|---|---|
| Volume Container | 16 m³ | 18 m³ | 20 m³ | 22 m³ | 24 m³ |
| Length (without rear hook) | 6050 mm | 6450 mm | 6850 mm | 7250 mm | 7650 mm |
| Length (with rear hook) | 6250 mm | 6650 mm | 7050 mm | 7450 mm | 7850 mm |
| Width x Height | 2460 x 2704 mm | 2460 x 2704 mm | 2460 x 2704 mm | 2460 x 2704 mm | 2460 x 2704 mm |
| Height of opening | 1400 mm | 1400 mm | 1400 mm | 1400 mm | 1400 mm |
| Volume/stroke | 1.9 m³ | 1.9 m³ | 1.9 m³ | 1.9 m³ | 1.9 m³ |
| Height of press ram | 700 mm | 700 mm | 700 mm | 700 mm | 700 mm |
| Feed opening WxL | 1860 x 1450 mm | 1860 x 1450 mm | 1860 x 1450 mm | 1860 x 1450 mm | 1860 x 1450 mm |
| Filling opening W x L | 1860 x 2153 mm | 1860 x 2153 mm | 1860 x 2153 mm | 1860 x 2153 mm | 1860 x 2153 mm |
| Compression force | 340 kN | 340 kN | 340 kN | 340 kN | 340 kN |
| Time taken for compression action | 55 s | 55 s | 55 s | 55 s | 55 s |
| Motor rating | 5.5 kW | 5.5 kW | 5.5 kW | 5.5 kW | 5.5 kW |
| Slow fuse | 16 A | 16 A | 16 A | 16 A | 16 A |
| Unloaded weight | 5060 kg | 5210 kg | 5360 kg | 5510 kg | 5660 kg |
| Cone | 3 x 100 mm | 3 x 100 mm | 3 x 100 mm | 3 x 100 mm | 3 x 100 mm |
